Components > Pixelated Carousel

Pixelated Carousel

The Pixelated Carousel is a React component that transforms image galleries with a pixelated animation effect. Built with Next.js and Framer Motion, it cycles through images with a dynamic grid overlay. Ideal for portfolios and product showcases, it offers customizable pixel size and transition duration, enhancing user engagement and visual appeal.

Preview

pixelated carouselpixelated carouselpixelated carouselpixelated carousel

Follow below steps 👇🏻

Component

Create a file pixelated-carousel.tsx in your components folder and paste this code

'use client'; import Image from 'next/image'; import React, { useEffect, useRef, useState, useMemo, useCallback } from 'react'; import { motion } from 'framer-motion'; const PixelatedCarousel = ({ pixelSize = 100, animationDelayStep = 0.02, images, pixelTransitionDuration = 0.1 }: { pixelSize?: number; animationDelayStep?: number; images: string[]; pixelTransitionDuration?: number; }) => { const [activeImageIndex, setActiveImageIndex] = useState(0); const ref = useRef<HTMLDivElement>(null); const [grid, setGrid] = useState<{ rows: number; cols: number }>({ rows: 0, cols: 0 }); const [isInitialized, setIsInitialized] = useState(false); const [isFirstCycle, setIsFirstCycle] = useState(true); const SIZE = pixelSize; const ANIMATION_DELAY_STEP = animationDelayStep; const PIXEL_TRANSITION_DURATION = pixelTransitionDuration; const sizeOfBox = useMemo(() => { if (!ref.current || grid.rows === 0 || grid.cols === 0) { return { h: 0, w: 0 }; } const height = ref.current.clientHeight; const width = ref.current.clientWidth; return { h: height / grid.rows, w: width / grid.cols }; }, [grid.rows, grid.cols]); const shuffledDelays = useMemo(() => { const totalBoxes = grid.rows * grid.cols; if (totalBoxes === 0) return []; const delays = Array.from({ length: totalBoxes }, (_, i) => i * PIXEL_TRANSITION_DURATION); for (let i = delays.length - 1; i > 0; i--) { const j = Math.floor(Math.random() * (i + 1)); [delays[i], delays[j]] = [delays[j], delays[i]]; } return delays; }, [grid.rows, grid.cols, PIXEL_TRANSITION_DURATION]); const boxState = useMemo(() => { if (shuffledDelays.length === 0) return []; return shuffledDelays.map((delay) => { const baseShade = 20 - Math.floor(Math.random() * 20); return { delay, color: `rgb(${baseShade}, ${baseShade}, ${baseShade})` }; }); }, [shuffledDelays]); const calculateGrid = useCallback(() => { if (!ref.current) return { rows: 0, cols: 0 }; const height = ref.current.clientHeight; const width = ref.current.clientWidth; const rows = Math.floor(height / SIZE); const cols = Math.floor(width / SIZE); return { rows, cols }; }, [SIZE]); const initialize = useCallback(() => { const newGrid = calculateGrid(); setGrid((prev) => { if (prev.rows === newGrid.rows && prev.cols === newGrid.cols) { return prev; } return newGrid; }); setIsInitialized(true); }, [calculateGrid]); useEffect(() => { initialize(); const handleResize = () => initialize(); window.addEventListener('resize', handleResize); return () => window.removeEventListener('resize', handleResize); }, [initialize]); useEffect(() => { if (!isInitialized || grid.rows === 0 || grid.cols === 0) return; const allBoxesBlackTime = ANIMATION_DELAY_STEP * (grid.rows * grid.cols - 1) + PIXEL_TRANSITION_DURATION; if (isFirstCycle) { const firstTimeout = setTimeout(() => { setActiveImageIndex((prev) => (prev + 1) % images.length); setIsFirstCycle(false); }, allBoxesBlackTime * 1000); return () => clearTimeout(firstTimeout); } else { const id = setInterval(() => { setActiveImageIndex((prev) => (prev + 1) % images.length); }, allBoxesBlackTime * 1000 * 2); return () => clearInterval(id); } }, [ images.length, grid.rows, grid.cols, isInitialized, isFirstCycle, ANIMATION_DELAY_STEP, PIXEL_TRANSITION_DURATION ]); const gridElements = useMemo(() => { if (!isInitialized || grid.rows === 0 || grid.cols === 0) return null; return Array.from({ length: grid.rows }).map((_, row) => ( <span key={row} className="flex"> {Array.from({ length: grid.cols }).map((_, col) => { const boxIndex = row * grid.cols + col; const box = boxState[boxIndex]; if (!box) return null; return ( <motion.span key={col} style={{ height: sizeOfBox.h, width: sizeOfBox.w, backgroundColor: box.color }} initial={{ opacity: 0 }} animate={{ opacity: 1 }} transition={{ duration: PIXEL_TRANSITION_DURATION, repeat: Infinity, repeatType: 'reverse', delay: box.delay, repeatDelay: grid.rows * grid.cols * ANIMATION_DELAY_STEP }} /> ); })} </span> )); }, [ isInitialized, grid.rows, grid.cols, boxState, sizeOfBox, PIXEL_TRANSITION_DURATION, ANIMATION_DELAY_STEP ]); return ( <div ref={ref} className="h-full w-full relative"> {isInitialized && <span className="h-full w-full absolute z-10">{gridElements}</span>} <div className="h-full w-full z-0 relative"> {images.map((image, index) => ( <Image src={image} key={image + index} alt="pixelated carousel" fill className="object-cover absolute top-0 left-0 h-full w-full" style={{ zIndex: activeImageIndex === index ? 10 : 0 }} /> ))} </div> </div> ); }; export default PixelatedCarousel;

Usage

<div className="h-[1000px] w-full flex items-center justify-center"> <div className="h-[500px] w-[800px]"> <PixelatedCarousel pixelSize={50} pixelTransitionDuration={0.01} images={['/godofwar.jpg', '/lastofus.jpg', '/rdr2.jpg', '/uncharted.jpg']} /> </div> </div>
