File Stack
A modern, interactive 3D file stack component built with React and Framer Motion. Features smooth hover animations, customizable spacing, and a two-column layout perfect for showcasing portfolios, image galleries, or file collections. Items stack with perspective depth and rotate elegantly on hover, revealing detailed information in an adjacent panel.
Preview
Install dependencies
npm i framer-motion tailwindcss-animate tailwindcssComponent
Create a file file-stack.tsx in your components folder and paste this code
'use client';
import Image from 'next/image';
import React, { useState } from 'react';
import { motion, AnimatePresence } from 'framer-motion';
type FileStackItem = {
title: string;
image: string;
description: string;
link?: string; // Optional link for clickable items
};
interface FileStackProps {
items: FileStackItem[];
spacing?: number; // Customizable spacing between items
}
const FileStack = ({ items, spacing = 10 }: FileStackProps) => {
const [isHovered, setIsHovered] = useState<number | null>(null);
const [isLoading, setIsLoading] = useState<{ [key: string]: boolean }>({});
// Subtle floating animation
const floatingAnimation = {
y: [0, -5, 0],
transition: {
duration: 4,
repeat: Infinity,
ease: 'easeInOut'
}
};
// Calculate consistent spacing value for each card
const getCardSpacing = (index: number) => {
if (index === 0) return 0;
return `-${spacing}rem`;
};
return (
<div className="h-full w-full relative group grid grid-cols-2">
<div className="overflow-y-auto h-full max-h-[500px]">
<div
style={{ perspective: '1000px' }}
className="flex flex-col h-full w-full items-center overflow-y-auto relative pt-[20%]"
>
{items.map((item, i) => (
<motion.div
key={i}
onMouseEnter={() => setIsHovered(i)}
onMouseLeave={() => setIsHovered(null)}
initial={{
rotateX: -50,
marginTop: getCardSpacing(i)
}}
animate={!isHovered ? floatingAnimation : undefined}
whileHover={{
rotateX: 0,
marginBottom: '7rem',
scale: 1.02,
boxShadow:
'0 0 30px 5px rgba(255, 255, 255, 0.2), inset 0 0 15px rgba(255, 255, 255, 0.1)',
transition: { duration: 0.3 }
}}
className={`
flex relative rounded-md flex-col items-center
max-w-[500px] justify-center bg-neutral-800 p-2
${item.link ? 'cursor-pointer' : ''}
transition-shadow duration-300
hover:shadow-xl hover:shadow-neutral-900/20
`}
onClick={() => item.link && window.open(item.link, '_blank')}
>
{/* FileStack Edge Detail */}
<div className="h-4 w-20 bg-neutral-800 rounded-ss-md rounded-se-md absolute -top-2" />
{/* Loading State */}
{isLoading[item.image] && (
<div className="absolute inset-0 flex items-center justify-center bg-neutral-800/50">
<div className="animate-spin rounded-full h-8 w-8 border-t-2 border-white" />
</div>
)}
{/* Image */}
<div className="relative w-full overflow-hidden rounded-sm">
<Image
src={item.image}
alt={item.title}
height={400}
width={400}
className="object-cover h-full max-w-[350px] transition-all duration-300"
onLoadingComplete={() =>
setIsLoading((prev) => ({ ...prev, [item.image]: false }))
}
onLoadStart={() => setIsLoading((prev) => ({ ...prev, [item.image]: true }))}
priority={i < 2}
/>
</div>
{/* Hover Indicator */}
<motion.div
className="absolute bottom-0 left-1/2 -translate-x-1/2 w-1/3 h-1 bg-white/50 rounded-full"
initial={{ scaleX: 0 }}
whileHover={{ scaleX: 1 }}
/>
</motion.div>
))}
</div>
</div>
<div className="h-full relative flex items-center justify-center w-full bg-gradient-to-b from-[#000000da] pointer-events-none to-transparent rounded-lg z-10">
<AnimatePresence mode="popLayout">
{isHovered !== null && (
<motion.div
key={isHovered + 'text'}
initial={{ opacity: 0, y: 100 }}
animate={{ opacity: 1, y: 0, transition: { delay: 0.2 } }}
exit={{ opacity: 0, y: -100 }}
transition={{ duration: 0.2 }}
className="flex flex-col items-center justify-center mt-2 p-4"
>
<h2 className="text-center font-bold text-2xl mb-2">
{items[isHovered].title}
</h2>
<p className="text-center text-neutral-300 max-w-[500px] line-clamp-2">
{items[isHovered].description}
</p>
</motion.div>
)}
</AnimatePresence>
</div>
</div>
);
};
export default FileStack;Usage
<FileStack
items={[
{
title: 'Porsche 911 2002',
image: 'https://ky008ymy6s.ufs.sh/f/NFGlOqM3XnMdjLyAKgGqhEeqvZJgkrY5a7DO6GR9iSLoX2ux',
description:
'The Porsche 911 2002, a classic sports car, known for its sleek design and powerful performance.'
},
{
title: 'Porsche 911 2006',
image: 'https://ky008ymy6s.ufs.sh/f/NFGlOqM3XnMdgxwkfk9uPKzfJUXx2s178trCpqad9inWYH0h',
description:
'The Porsche 911 2006, a refined model with enhanced features, offering a thrilling driving experience.'
},
{
title: 'Porsche 911 2010',
image: 'https://ky008ymy6s.ufs.sh/f/NFGlOqM3XnMdfZWfaKSfCnAtBkxgmdb2qeojV0MJ35iYWUKs',
description:
'The Porsche 911 2010, a modern icon, combining luxury and speed with cutting-edge technology.'
},
{
title: 'Porsche 911 2014',
image: 'https://ky008ymy6s.ufs.sh/f/NFGlOqM3XnMd78gyAVfu5KZwfqtoI3FbhBdTzArEGPxLSU8Q',
description:
'The Porsche 911 2014, a masterpiece of engineering, delivering unmatched performance and style.'
},
{
title: 'Porsche 911 2018',
image: 'https://ky008ymy6s.ufs.sh/f/NFGlOqM3XnMd25OfuK3bHkp8iXl9yEqgCjP7chLrsd4WfKaD',
description:
'The Porsche 911 2018, a pinnacle of automotive excellence, offering a perfect blend of tradition and innovation.'
}
]}
></FileStack>
